Deploying Machine Learning Models with PyTorch, gRPC and asyncio

Today we're going to see how to deploy a machine-learning model behind gRPC service running via asyncio. gRPC promises to be faster, more scalable, and more optimized than HTTP v1.

gRPC is supported in all major programming languages and will create types hints, client, and server code for you, making it easier to incorporate a new service in your stack. This is a good article about gRPC pros and cons, feel free to have a look before.

We will use PyTorch to create an image classifier and perform inference using gRPC calls. The code is hosted on GitHub.

What is gRPC?

gRPC is a Remote Procedure Call (RPC) framework that runs on any device. gRPC is mainly developed and maintained by Google and it's widely used in the industry. It allows two machines to communicate, similar to HTTP, but with better syntax and performance. It's used to define microservices that may use different programming languages.

gRPC works by defining the fields of the messages the client and server will exchange and the signature of the function we will expose, with a special syntax in a .proto file, then gRPC generates both client and server code and you can call the function directly from the client.

gRPC services send and receive data as Protocol Buffer (Protobuf) messages, they can be better compressed than human-readable format (like JSON or XML), thus the better performance.

Getting Started

Let's start by setting up a virtual environment in which we can build our project:

python -m venv .venv

Then, let's install all the required packages, grpcio, grpcio-tools, torch, torchvision and Pillow

pip install grpcio grpcio-tools torch torchvision Pillow==9.3.0

Now we're ready to start building! In this project, we will work on 4 files:

.
└── src
    ├── client.py
    ├── inference.proto
    ├── inference.py
    └── server.py

• client.py holds the client code we will use to send inference requests
• server.py holds the server code responsible of receiving the inference request and sending a reply
• inference.py holds the actual model and inference logic
• inference.proto holds the protocol buffer messages definition

Let's start by coding our model inside inference.py

Making Inferences with Resnet34

We will use resnet34 from torchvision. First thing, we define our preprocessing transformation:

# inference.py
import torchvision.transforms as T

preprocess = T.Compose(
    [
        T.Resize((224, 224)),
        T.ToTensor(),
        T.Normalize(
            mean=[0.485, 0.456, 0.406],
            std=[0.229, 0.224, 0.225],
        ),
    ]
)


if __name__ == "__main__":
    from PIL import Image
    image = Image.open('./examples/cat.jpg')
    tensor = preprocess(image)
    print(tensor.shape)

This code imports a torchvision transformer, sets up a preprocessing transformation, and applies that transformation to an example image called cat.jpg.

# inference.py
from typing import List

import torch
import torchvision.transforms as T
from PIL import Image
from torchvision.models import ResNet34_Weights, resnet34

preprocess = ...
model = resnet34(weights=ResNet34_Weights.IMAGENET1K_V1).eval()


@torch.no_grad()
def inference(images: List[Image.Image]) -> List[int]:
    batch = torch.stack([preprocess(image) for image in images])
    logits = model(batch)
    preds = logits.argmax(dim=1).tolist()
    return preds


if __name__ == "__main__":
    image = Image.open("./examples/cat.jpg")
    print(inference([image]))

The model will output 262, which is the right class for our cat. Our inference function takes a list of Pil images and creates a batch, then it collects the right classes and converts them to a list of class ids.

Nice, we have our model setup.

How to Build a gRPC Server

The next step is to create the actual gRPC server. First, we describe the message and the service in the .proto file.

A list of all types of messages can be found here and the official python tutorial for gRPC here.

Proto

We will start by defining our InferenceServer service

// inference.proto

syntax = "proto3";

// The inference service definition.
service InferenceServer {
  // Sends a inference reply
  rpc inference (InferenceRequest) returns (InferenceReply) {}
}

This tells gRPC we have an InferenceServer service with an inference function, notice that we need to specify the type of the messages: InferenceRequest and InferenceReply

// inference.proto
...
// The request message containing the images.
message InferenceRequest {
    repeated bytes image = 1;
}

// The response message containing the classes ids
message InferenceReply {
    repeated uint32 pred = 1;
}

Our request will send a list of bytes (images), the repeated keyword is used to define lists, and we will send back a list of predictions

How to Build the Server and Client

Now, we need to generate the client and server code using grpcio-tools (we installed it at the beginning).

cd src && python -m grpc_tools.protoc -I . --python_out=. --pyi_out=. --grpc_python_out=. inference.proto

This will generate the following files

└── src
    ├── inference_pb2_grpc.py
    ├── inference_pb2.py
    ├── inference_pb2.pyi
    ...

• inference_pb2_grpc contains our gRPC's server definition
• inference_pb2 contains our gRPC's messages definition
• inference_pb2 contains our gRPC's messages types definition

We now have to code our service,

# server.py
# we will use asyncio to run our service
import asyncio
...
# from the generated grpc server definition, import the required stuff
from inference_pb2_grpc import InferenceServer, add_InferenceServerServicer_to_server
# import the requests and reply types
from inference_pb2 import InferenceRequest, InferenceReply
...

To create the gRPC server we need to import InferenceServer and add_InferenceServerServicer_to_server from the generated inference_pb2_grpc. Our logic will go inside a subclass of InferenceServer in the inference function, the one we defined in the .proto file.

# server.py
class InferenceService(InferenceServer):
    def open_image(self, image: bytes) -> Image.Image:
        image = Image.open(BytesIO(image))
        return image

    async def inference(self, request: InferenceRequest, context) -> InferenceReply:
        logging.info(f"[🦾] Received request")
        start = perf_counter()
        images = list(map(self.open_image, request.image))
        preds = inference(images)
        logging.info(f"[✅] Done in {(perf_counter() - start) * 1000:.2f}ms")
        return InferenceReply(pred=preds)

Notice we subclass InferenceServer, we add our logic inside inference and we label it as an async function, this is because we will lunch our service using asyncio.

We now need to tell gRPC how to start our service.

# server.py
...
from inference_pb2_grpc import InferenceServer, add_InferenceServerServicer_to_server
import logging

logging.basicConfig(level=logging.INFO)

async def serve():
    server = grpc.aio.server()
    add_InferenceServerServicer_to_server(InferenceService(), server)
    # using ip v6
    adddress = "[::]:50052"
    server.add_insecure_port(adddress)
    logging.info(f"[📡] Starting server on {adddress}")
    await server.start()
    await server.wait_for_termination()

Line by line, we create a grpc asyncio server using grpc.aio.server(), we add our service by passing it to add_InferenceServerServicer_to_server then we listed on a custom port using ipv6 by calling the .add_insecure_port method and finally we await the .start server method.

Finally,

# server.py
if __name__ == "__main__":
    asyncio.run(serve())

If you now run the file

python src/server.py

You'll see

INFO:root:[📡] Starting server on [::]:50052

The full server looks like

import asyncio
from time import perf_counter

import grpc
from PIL import Image
from io import BytesIO
from inference import inference
import logging
from inference_pb2_grpc import InferenceServer, add_InferenceServerServicer_to_server
from inference_pb2 import InferenceRequest, InferenceReply

logging.basicConfig(level=logging.INFO)


class InferenceService(InferenceServer):
    def open_image(self, image: bytes) -> Image.Image:
        image = Image.open(BytesIO(image))
        return image

    async def inference(self, request: InferenceRequest, context) -> InferenceReply:
        logging.info(f"[🦾] Received request")
        start = perf_counter()
        images = list(map(self.open_image, request.image))
        preds = inference(images)
        logging.info(f"[✅] Done in {(perf_counter() - start) * 1000:.2f}ms")
        return InferenceReply(pred=preds)


async def serve():
    server = grpc.aio.server()
    add_InferenceServerServicer_to_server(InferenceService(), server)
    # using ip v6
    adddress = "[::]:50052"
    server.add_insecure_port(adddress)
    logging.info(f"[📡] Starting server on {adddress}")
    await server.start()
    await server.wait_for_termination()


if __name__ == "__main__":
    asyncio.run(serve())

Sweet! We have our gRPC running with asyncio. We now need to define our client.

Creating and Defining a Client

Creating a client is straightforward, similar to before we need the definitions that were generated in the previous step.

# client.py

import asyncio

import grpc

from inference_pb2 import InferenceRequest, InferenceReply
from inference_pb2_grpc import InferenceServerStub

InferenceServerStub is the gRPC communication point. Let's create our async function to send InferenceRequest and collect InferenceReply

...
import logging

logging.basicConfig(level=logging.INFO)

async def main():
    async with grpc.aio.insecure_channel("[::]:50052 ") as channel:
        stub = InferenceServerStub(channel)
        start = perf_counter()

        res: InferenceReply = await stub.inference(
            InferenceRequest(image=[image_bytes])
        )
        logging.info(
            f"[✅] pred = {pformat(res.pred)} in {(perf_counter() - start) * 1000:.2f}ms"
        )

We define our channel using grpc.aio.insecure_channel context manager, we create an instance of InferenceServerStub and we await the .inference method. The .inference method takes InferenceRequest instance containing our images in bytes. We receive back an InferenceReply instance and we print the predictions.

To get the bytes from an image, we can use Pillow and BytesIO

from io import BytesIO
from PIL import Image

# client.py

image = Image.open("./examples/cat.jpg")
buffered = BytesIO()
image.save(buffered, format="JPEG")
image_bytes = buffered.getvalue()

The full client code looks like

import asyncio
from io import BytesIO

import grpc
from PIL import Image

from inference_pb2 import InferenceRequest, InferenceReply
from inference_pb2_grpc import InferenceServerStub
import logging
from pprint import pformat
from time import perf_counter

image = Image.open("./examples/cat.jpg")
buffered = BytesIO()
image.save(buffered, format="JPEG")
image_bytes = buffered.getvalue()

logging.basicConfig(level=logging.INFO)


async def main():
    async with grpc.aio.insecure_channel("[::]:50052 ") as channel:
        stub = InferenceServerStub(channel)
        start = perf_counter()

        res: InferenceReply = await stub.inference(
            InferenceRequest(image=[image_bytes])
        )
        logging.info(
            f"[✅] pred = {pformat(res.pred)} in {(perf_counter() - start) * 1000:.2f}ms"
        )


if __name__ == "__main__":
    asyncio.run(main())

Let's run it!

python src/client.py

It results in the following output in the client

// client
INFO:root:[✅] pred = [282] in 86.39ms

and on the server

// server
INFO:root:[🦾] Received request
INFO:root:[✅] Done in 84.03ms

Nice! We can also pass multiple images,

# client.py
...
        res: InferenceReply = await stub.inference(
                    InferenceRequest(image=[image_bytes, image_bytes, image_bytes])
                )

We just copied and pasted [image_bytes, image_bytes, image_bytes] to send 3 images

If we run it,

python src/client.py

We get

INFO:root:[✅] pred = [282, 282, 282] in 208.39ms

Yes, 3 predictions on the same gRPC call! 🚀🚀🚀

Deploy a Machine Learning Model Using PyTorch, gRPC and asyncio

Today we have seen how to deploy a machine learning model using PyTorch, gRPC and asyncio. Scalable, effective, and performant to make your model accessible. There are many gRPC features, like streaming, we didn't touch and encourage you to explore other gRPC features.

I hope it helps!

See you in the next one,

Francesco
